TH1255 Telehandler

  • Vista exterior
  • Vista interior
Solicitar presupuesto

Motor - Estándar

Modelo
Cat C3.6
Emisiones
Meets U.S. EPA Tier 4 Final/EU Stage V emissions standards.
Potencia bruta
ISO 14396:2002
Potencia bruta
74 CV
Desplazamiento
220 pulg.

Engine - Option 1

Modelo*
Cat C3.6
Emisiones
Meets U.S. EPA Tier 4 Final/EU Stage V emissions standards.
Potencia bruta
ISO 14396:2002
Potencia bruta
115 CV
Desplazamiento
220 pulg.

Especificaciones de funcionamiento

Capacidad de carga nominal
12.000 libras
Altura máxima de elevación
55 pies
Alcance máximo hacia delante
41 pies
Nivelación del bastidor
10 grados
Tirador de la barra de tracción - Cargado
29,225 lbf
Capacity at Maximum Lift Height (Stabilizers Down)
5.000 libras
Capacity at Maximum Forward Reach (Stabilizers Down)
3.500 libras
Peso operativo
31,238 lb
Maximum Ground Bearing Pressure (Solid Tires)
230 psi
Maximum Ground Bearing Pressure (Pneumatic Tires)
175 psi
Travel Speed – Forward
18 millas/h
Travel Speed – Reverse
13 millas/h
Turning Radius over Tires (2-wheel steer)
259 in³
Turning Radius over Tires (4-wheel steer)
157 en
Nota
Operating Specifications, and Dimensions are based on 55 kW (74 hp) engine, pnuematic tires, open canopy, 1829 mm (72 in) standard carriage, 1829 mm (72 in) forks, full fluids, and 80 kg (176 hp) engine.
Nota (1)
Travel Speeds and Drawbar Pull are based on the 86 kW (115 hp) engine.

Weight Additions (add to base configured weight)

Engine*
194 libras
Enclosed Cab (with Air Conditioning)
364 libras
Solid Tires
1.905 libras
Fenders (set of 4)
119 libras
Nota
* 86 kW (115 hp) Engine

Sistema hidráulico

Flujo hidráulico auxiliar
15 gpm
Presión hidráulica auxiliar
4.061 psi
Maximum Pump Flow
37 gpm
System Operating Pressure
4.061 psi

Capacidades de recarga de servicio

Depósito de combustible
39 galones (US)
Depósito de líquido de escape diésel (DEF)
5 galones (US)
Depósito hidráulico
24 galones (US)
Sistema hidráulico
44 galones (US)
Cárter del motor
2 galones (US)
Transmisión
5 galones (US)
Transfer Case
1 galón (US)
Nota
Diesel Exhaust Fluid (DEF) is only applicable for 86 kW (115 hp) engine option.

Velocidades de transmisión

Adelante
4 Gears
Invertir
3 Gears

Neumáticos

Option (1)
17.5-25 Galaxy Giraffe XLW L-2 (Air)
Option (2)
14-24 Camso TLH 792S (Solid)
Option (3)
14-24 Maxam MS709 (Solid)

Sistema de frenado

Frenos de servicio
Frenos de disco en baño de aceite en los ejes delantero y trasero
Frenos de estacionamiento
Wet disc, spring applied hydraulic release (front axle)

Rendimiento de la pluma

Boom Abajo
18.1 sec
Boom Up
16.4 sec
Tele In
19.4 sec
Tele Out
20.5 sec

Dimensiones (aproximadas)

Height - Machine Rear
106 en
Overall Length to Front of Carriage
252 en
Overall Width - Stabilizers Down
146 en
Overall Width - Standard Tires
97 en
Distancia entre ejes
131 en
Distancia al suelo
18 en

Sistema de aire acondicionado

Aire acondicionado
The air conditioning system on this machine contains 0.68 kg (1.5 lb) of refrigerant. The refrigerant is either R134a or R1234yf. If equipped with R134a (Global Warming Potential = 1430), the refrigerant in the system has a CO2 equivalent of 0.972 metric

Sostenibilidad

Reciclabilidad
98%

Sonido

Exterior Sound
82 dB(A)
Operator Sound
79 dB(A)

Comfortable Operator Station

Cat Telehandlers offer a roomy operator station, with standard features like a tilt steering column, dual charging ports, cupholder, and options like an enclosed cab with air conditioning and a top window sunshade to deliver excellent comfort when operating.

Easy To Operate

Pilot controlled joystick with excellent multi-function capability, makes the Cat Telehandler easy to use. The intuitive LCD monitor provides easy to read machine information, with a choice of languages, and delivers a standard multi-operator code security system.

Safety On The Job Site

Your safety is our top priority and the Cat Telehandler is designed to help keep you safer on the job. Standard equipment like the load stability indication (LSI) system, operator presence seat switch, rearview camera, high-visibility orange seat belt, and optional features such as the seat belt reminder system and hydraulic lockout switch, are just a few of the safety features we’ve built into the machine.

Simple Service For More Uptime

With extended service intervals, spend more time working and less time on maintenance with Cat Telehandlers. Daily check points are at ground level with grouped service points, and an easy-to-use service tool that allows quick checks of the chain for tension, link wear, or stretching. And rest easy with the standard 5-year/5,000-hour warranty for the main frame, boom, stabilizer frame and stabilizers.

Menores costes de explotación

Equipped with features such as 500-hour greasing interval, 500-hour boom maintenance interval, 3,000-hour hydraulic oil, 6,000-hour extended life coolant, engine idle shutdown, and efficient hydraulics with a variable displacement pump, the Cat Telehandler was designed to help reduce your operating costs.

Accesorios para gatos

Combining a wide selection of Cat Telehandler attachments with either the industry-standard TH coupler or the Integrated Tool Carrier (IT) coupler, the Next Generation Cat Telehandlers deliver exceptional versatility to meet the varied demands of today's job sites.

  • Motor
    • 55 kW (74 hp)
  • Tiempo frío
    • Desconexión de la batería con función de bloqueo
  • Puesto de operador
    • Canopy
  • Operating Enhancers
    • Operator Presence Seat Switch
    • Cámara de visión trasera
    • Load Stability Indicator (LSI)
  • Operator Seat
    • Seat – Mechanical Suspension
  • Cinturón de seguridad
    • Seat belt – 51 mm (2 in)
  • Operator Station Accessories
    • USB dual charging port (USB-A and USB-C)
    • Security, 4 digit operator code enabled
    • Wiper, front (enclosed cab only)
  • Guardabarros
    • Cab fender (Left Hand front)
  • Other Options
    • Frame cover
    • Retrieval hitch
  • Luces
    • LED work lights – cab, boom
  • Telemática
    • PLE643 – Product Link™ Elite
  • Attachment Coupler
    • TH Coupler (Manual)
  • Auxiliary Hydraulic Connections
    • Capped auxiliary hydraulic lines
  • Stabilizers
    • Front Stabilizers
  • Motor
    • 86 kW (115 hp)
  • Tiempo frío
    • Cold Weather Package
    • Dual Battery, heavy duty
    • Engine Block Heater
    • Ether Starting Aid
  • Puesto de operador
    • Enclosed Cab, heat
    • Enclosed Cab, heat, air conditioner
  • Operator Seat
    • Seat – Mechanical Suspension Plus
  • Cinturón de seguridad
    • Seat belt – 75 mm (3 in)
    • Seat belt with Indicator – 75 mm (3 in)
  • Operator Station Accessories
    • Security, Bluetooth® key
    • Hydraulic lockout switch
    • Wiper, rear (enclosed cab only)
    • Wiper, roof (enclosed cab only)
    • Sunshade (top window)
    • Padlocks (set of 4)
  • Guardabarros
    • Fenders (4 Wheels)
  • Vigilancia
    • Window guard, front
    • Window guard, top
  • Other Options
    • Boom prop
  • Luces
    • Faro
    • Roading lights
  • Neumáticos
    • Galaxy – pneumatic directional
    • Camso – solid directional
    • Maxam – solid non-directional
  • Attachment Coupler
    • IT Coupler (Manual)
    • IT Coupler (Hydraulic)
  • Auxiliary Hydraulic Connections
    • Twist to connect hydraulic quick disconnects
  • Carriage
    • Standard – 1270 mm (50 in)
    • Standard – 1829 mm (72 in)
    • Side Tilt/Rotating – 1270 mm (50 in)
    • Side Tilt/Rotating – 1829 mm (72 in)
    • Hydraulic Fork Positioner – 1829 mm (72 in)
  • Horquillas
    • Pallet Forks – 1220 mm (48 in)
    • Pallet Forks – 1525 mm (60 in)
    • Pallet Forks – 1829 mm (72 in)
  • Other Work Tool Attachments
    • General Purpose Bucket
    • Truss Boom – 3.7 m (12 ft)
