C18 ACERT™ Tier 4 Final Engine

C18 ACERT™ Tier 4 Final Engine

Length 60 in.
Width 38 in.
Height 51 in.
Weight 3,482 lb
Minimum Rating 755 BHP
Maximum Rating 800 BHP
Request a Quote Download Brochure
Dimensions
Length 60 in.
Width 38 in.
Height 51 in.
Weight 3,482 lb
Length 60 in
Width 38 in
Height 51 in
Weight 3,482 lb
General Specifications
Minimum Rating 755 BHP
Maximum Rating 800 BHP
Governor and Protection ADEM A4
RPM 1,800 r/min
Aspiration Turbocharged-Aftercooled
Displacement 1,104 in³
Flywheel and Flywheel Housing SAE No. 0 or SAE No. 1
Flywheel Teeth 136 (SAE 0), 113 (SAE 1)
Rotation from Flywheel End Counterclockwise
Stroke 7 in
Bore 6 in
Emissions
Emissions EPA Tier 4 Final and EU Stage IV
Capacity for Liquids
Cooling System 7 gal (US)

Advanced Digital Engine Management

ADEM A4 control system providing integrated ignition, speed governing, protection, and controls, including detonationsensitive variable ignition timing. ADEM A4 has improved: user interface, display system, shutdown controls, and system diagnostics.

Custom Packaging

For any petroleum application, trust Caterpillar to meet your project needs with custom factory generator sets and mechanical packages. Cat engines, generators, controls, radiators, and transmissions can be custom designed and matched in collaboration with our local dealers to create unique solutions. Custom packages are globally supported and are covered by a one year warranty after startup.

Fuel & Oil

Requires Ultra Low Sulfur Diesel (ULSD) containing a maximum of 15 ppm sulfur, and new oil formulations to support the new technology. Designed to accommodate B20 biofuel.

Transmissions

- Caterpillar has a full line of engine-transmission packages that can be fully integrated with your axle, hydraulics, and operator interface. - C18 ACERT™ Caterpillar optimized transmission matches: CX35-P800

Product Support Offered Through Global Cat Dealer Network

- More than 2,200 dealer outlets - Cat factory-trained dealer technicians service every aspect of your petroleum engine - Cat parts and labor warranty - Preventive maintenance agreements available for repair-beforefailure options - S•O•SSM program matches your oil and coolant samples against Caterpillar set standards to determine: - Internal engine component condition - Presence of unwanted fluids - Presence of combustion by-products - Site-specific oil change interval

Over 80 Years of Engine Manufacturing Experience

Ownership of these manufacturing processes enables Caterpillar to produce high quality, dependable products.

Over 80 Years of Engine Manufacturing Experience

Ownership of these manufacturing processes enables Caterpillar to produce high quality, dependable products.

Website

For all your petroleum power requirements, visit www.cat.com/oilandgas.

  • Air Inlet System
    • Turbocharged Aftercooled
  • Control System
    • Electronic control system, over-foam wiring harness, automatic altitude compensation, power compensated for fuel temperature, configurable software features, engine monitoring system SAE J1939 broadcast and control, integrated Electronic Control Unit (ECU) remote fan control
  • Cooling System
    • Vertical outlet thermostat housing, centrifugal water pump
  • Exhaust System
    • Dry exhaust manifold, Diesel Oxidation Catalyst (DOC)
  • Flywheels And Flywheel Housing
    • SAE 0 and SAE 1 flywheel housing
  • Fuel System
    • MEUI injection; primary fuel filter, secondary fuel filters, fuel transfer pump, electronic fuel priming
  • Lube System
    • Open crankcase ventilation system, oil cooler, oil filler, oil filter, oil dipstick, oil pump (gear driven), choice of sumps (front, rear, high-capacity center, and high-capacity front)
  • Power Take Off
    • SAE B and SAE C drives available, engine power can also be taken from the front of the engine on some applications
  • General
    • Paint: Cat yellow; vibration damper; lifting eyes
×
