Dimensions
- Impact Energy Class
- 2,950 ft-lbf
- Blows per Minute
- 400-800
- Min. Rated Flow
- 33 gal/min
- Max. Rated Flow
- 40 gal/min
- Max. Operating Weight
- 3,527 lb
- Minimum Operating Weight
- 3,859 lb
- Maximum Operating Pressure
- 2,610 psi
- Minimum Operating Pressure
- 2,320 psi
- Maximum Carrier Weight
- 55,115 lb
- Minimum Carrier Weight
- 39,683 lb
- Tool Diameter
- 5 in
- Impact Energy Class
- 2,950 ft-lb
- Blows per Minute
- 400-800
- Maximum Operating Weight
- 3,927 lb
- Maximum Rated Flow
- 1,785 kg
- Minimum Rated Flow
- 40 gal/min
- Tool Shaft Diameter
- 5 in
- Rated Flow - Minimum
- 33 gal/min
- Energy Class
- 16,000 kPa
- Operating Pressure
- NaN
- Operating Weight - With Tool
- 3,927 lb
- Operating Weight
- 1,754 kg
- Overall Height
- 39,683 lb
- Overall Length
- Rated Flow - Maximum
- 40 gal/min
- Impact Energy Class
- 2,950 ft-lb
- Blows per Minute
- 400 to 800
- Maximum Carrier Weight
- 55,115 lb
- Minimum Carrier Weight
- 39,683 lb
- Maximum Operating Weight
- 3,927 lb
- Minimum Operating Weight
- 3,849 lb
- Tool Shaft Diameter
- 5 in
- Maximum Operating Pressure
- 2,610 psi
- Minimum Operating Pressure
- 2,320 psi
- Rated Flow - Maximum
- 40 gal/min
- Rated Flow - Minimum
- 33 gal/min
High Performance
- Automatic shutoff offers blank firing protection by stopping the piston when there is no material under the tool to help extend the life of the hammer.
- Manually adjust the piston speed by choosing between high piston speed or maximum power to help increase efficiency and production on the job site.
- The standard silencing feature allows you to use a GC S hammer on job sites in noise sensitive areas like neighborhoods or near hospitals where noise is regulated.
Reliability and Durability
- The internal buffering system helps reduce machine vibration and increase noise suppression.
- Simple hammer design for easy maintenance and faster rebuilds to help lower owning and operating costs.
- Critical hydraulic components are shielded from damage inside the housing, helping decrease downtime on the job site.
Easy to Maintain
- Standard onboard autolube provides continuous greasing as the hammer runs, eliminating the need for manual greasing.
- The slip-fit lower bushing allows for easy replacement in the field, helping reduce service time.
- Verify the gas charge of the hammer without removing it from your machine.
- Quick and easy access to maintenance areas helps make hammer maintenance simple.
Boost Efficiency and Productivity with Integrated Technologies
- Never waste time looking for your attachments again. Cat asset tracking is available on all hammers.
- Track your entire fleet of attachments and machines from one source. Hammers with asset tracking can be viewed within VisionLink®.
- Keep your assets secure. Hammers with an asset tracker send an alert if they leave an easy-to-set-up site boundary.
