Engine
- Engine Model
-
Cat® C15
- Rated Speed
-
2000 rpm
- Peak Power Speed
-
1600 rpm
- Engine Power - ISO 14396
-
449 hp
- Gross Power - SAE J1995:2014
-
456 hp
- Net Power - SAE J1349:2011
-
448 hp
- Emissions
-
U.S. EPA Tier 4 Final, EU Stage V, and Japan 2014
- Bore
-
5 in
- Stroke
-
7 in
- Displacement
-
927 in³
- Peak Torque - 1,200 rpm - SAE J1995
-
1,778 ft·lbf
- Torque Rise
-
16%
- Peak Torque (1,200 rpm) - SAE J1995:2014
-
1,778 lbf·ft
- Note (1)
-
Two engine emission options are available: 1. Meets U.S. EPA Tier 4 Final, EU Stage V, and Japan emission standards. 2. Meets Brazil MAR-1 emission standards, equivalent to U.S. EPA Tier 3 and EU Stage IIIA.
- Note (2)
-
Net power advertised is the power available at the flywheel when the engine is equipped with fan at minimum speed, air intake system, exhaust system, and alternator.
- Note (3)
-
Net power at the flywheel when the fan is at maximum speed is 304 kW / 408 hp per SAE reference conditions.
Operating Specifications
- Operating Weight
-
112,426 lb
- Rated Payload - Quarry Face
-
13 ton (US)
- Bucket Capacity Range
-
6.4-7.6 m3 (8.3-10 yd3)
- Cat Truck Match - High Lift
-
772/773/775
Transmission
- Transmission Type
-
Cat planetary power shift
- Forward - 1
-
5 mile/h
- Forward - 2
-
8 mile/h
- Reverse - 1
-
5 mile/h
- Reverse - 2
-
8 mile/h
- Direct Drive - Forward 1
-
Lock-up disabled
- Direct Drive - Forward 2
-
8 mile/h
- Direct Drive - Forward 3
-
14 mile/h
- Direct Drive - Forward 4
-
24 mile/h
- Direct Drive - Reverse 2
-
9 mile/h
- Direct Drive - Reverse 3
-
16 mile/h
- Direct Drive - Reverse 4
-
25 mile/h
- Direct Drive - Reverse 1
-
Lock-up disabled
- Note
-
Travel speeds based on 35/65-R33 tires.
Hydraulic System - Lift/Tilt
- Lift/Tilt System - Circuit
-
EH - Load Sense
- Lift/Tilt System
-
2X x 145 cc Variable displacement piston
- Maximum Flow at 2,165 rpm
-
159 gal/min
- Relief Valve Setting - Lift/Tilt
-
4,598 psi
- Cylinders, Double Acting - Lift, Bore and Stroke
-
190 mm x 1216 mm (7.5 in x 48 in)
- Cylinders, Double Acting - Tilt, Bore and Stroke
-
170 mm x 722 mm (6.7 in x 28.4 in)
- Pilot System
-
Variable displacement piston
- Tilt Cylinder - Stroke
-
27 in
- Lift/Tilt System - Pump
-
Variable displacement piston
- Relief Valve Setting
-
500 psi
Hydraulic Cycle Times
- Rack Back
-
4 s
- Raise
-
8 s
- Dump
-
3 s
- Lower Float Down
-
5 s
- Total Hydraulic Cycle Time - Empty Bucket
-
19 s
Hydraulic System - Steering
- Steering System - Circuit
-
Pilot, load sensing
- Steering System - Pump
-
Piston, variable displacement
- Maximum Flow
-
52 gal (US)
- Relief Valve Setting - Steering
-
4,000 psi
- Total Steering Angle
-
70°
- Steering Cycle Times - High Idle
-
3 s
- Steering Cycle Times - Low Idle
-
5 s
- Maximum Flow at 2,165 rpm
-
52 gal/min
Air Conditioning System
- Air Conditioning
-
The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a or R1234yf. See the label or instruction manual for identification of the gas. - If equipped with R134a (Global Warming Potential = 1430), the system co
Axles
- Front
-
Fixed
- Rear
-
Trunnion
- Oscillation Angle
-
+/-12.5°
Brakes
- Brakes
-
ISO 3450:2011
Operator's Cab
- ROPS/FOPS
-
Rollover Protective Structure/Falling Objects Protective Structure (ROPS/FOPS) meet ISO 3471:2008 and ISO 3449:2005 Level II standards
Service Refill Capacities
- Fuel Tank
-
141 gal (US)
- Cooling System
-
27 gal (US)
- Engine Crankcase
-
9 gal (US)
- Diesel Exhaust Fluid Tank
-
6 gal (US)
- Transmission
-
20 gal (US)
- Differential - Final Drives - Front
-
49 gal (US)
- Differential - Final Drives - Rear
-
45 gal (US)
- Note
-
Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) and are compatible* with ULSD blended with the following lower-carbon intensity fuels** up to: - 20% biodiesel FAME (fatty acid methyl ester) *** - 10
- Hydraulic System Factory Fill
-
94 gal (US)
Sound Performance - Tier 4 Final/EU Stage V - Standard
- Operator Sound Level (ISO 6396)
-
72 dB(A)
- Machine Sound Level (ISO 6395)
-
110 dB(A)
- Note (1)
-
The operator sound pressure level was measured according to the test procedures and conditions specified in ISO 6396:2008. The measurement was conducted at 70 percent of the maximum engine cooling fan speed.
- Note (2)
-
Hearing protection may be needed when the machine is operated with a cab that is not properly maintained or when the doors or windows are open for extended periods or in a noisy environment.
- Note (3)
-
The machine sound power level was measured according to the test procedures and conditions specified in ISO 6395:2008. The measurement was conducted at 70 percent of the maximum engine cooling fan speed.
Dimensions (Approximate) - High Lift
- Ground to Top of ROPS
-
14 ft
- Ground to Top of Exhaust Stacks
-
13 ft
- Ground to Top of Hood
-
11 ft
- Rear Axle - Centerline to Bumper
-
10 ft
- Front Axle Centerline to Bucket Tip
-
17 ft
- Wheel Base
-
13 ft
- Maximum Overall Length
-
40 ft
- Ground to Lower Hitch Clearance
-
2 ft
- Clearance at Maximum Lift
-
12 ft
- B-Pin Height - Maximum Lift
-
19 ft
- Maximum Overall Height - Bucket Raised
-
25 ft
- Reach - Maximum Lift
-
8 ft
- Note
-
Specifications are calculated with 6.9 m3 (9.0 yd3 ) rock bucket equipped with Michelin XLDD1 35/65 R33 tires.
- Ground to Fuel Tank Clearance
-
2 ft
- Ground to Center of Front Axle
-
3 ft
- Clearance at Maximum Lift (45° Dump)
-
12 ft
- Reach at Maximum Lift (45° Dump)
-
8 ft
Buckets
- Bucket Capacities
-
6.4-7.6 m3 (8.3-10 yd3)
Sustainability
- Recyclability
-
96%
Sound Performance - Tier 4 Final / Stage V
- Operator Sound Pressure Level (ISO 6396:2008)
-
73 dB(A)
- Machine Sound Power Level (ISO 6395:2008)
-
113 dB(A)
- Operator Sound Pressure Level (ISO 6396:2008)*
-
72 dB(A)
- Machine Sound Power Level (ISO 6395:2008)**
-
110 dB(A)
- Note (1)
-
* For machines in European Union countries and in countries that adopt the “EU Directives” and “UK Directives.”
- Note (2)
-
** European Union Directive “2000/14/EC” as amended by “2005/88/EC” and UK Noise Regulation 2001 No. 1701.
- Note (3)
-
The machine sound power level was measured according to ISO 6395:2008. The measurement was conducted at 70% of the maximum engine cooling fan speed.
- Note (4)
-
The operator sound pressure level was measured according to ISO 6396:2008. The measurement was conducted at 70% of the maximum engine cooling fan speed.
- Note (5)
-
Hearing protection may be needed when the machine is operated with a cab that is not properly maintained or when the doors or windows are open for extended periods or in a noisy environment.
Sound Performance - Tier 3 / Stage IIIA
- Operator Sound Pressure Level (ISO 6396:2008)
-
74 dB(A)
- Machine Sound Power Level (ISO 6395:2008)
-
113 dB(A)
- Operator Sound Pressure Level (ISO 6396:2008)*
-
73 dB(A)
- Machine Sound Power Level (ISO 6395:2008)**
-
110 dB(A)
- Note (1)
-
* For machines in European Union countries and in countries that adopt the “EU Directives” and “UK Directives.”
- Note (2)
-
** European Union Directive “2000/14/EC” as amended by “2005/88/EC” and UK Noise Regulation 2001 No. 1701.
- Note (3)
-
The machine sound power level was measured according to ISO 6395:2008. The measurement was conducted at 70% of the maximum engine cooling fan speed.
- Note (4)
-
The operator sound pressure level was measured according to ISO 6396:2008. The measurement was conducted at 70% of the maximum engine cooling fan speed.
- Note (5)
-
Hearing protection may be needed when the machine is operated with a cab that is not properly maintained or when the doors or windows are open for extended periods or in a noisy environment.
